Description
| D | Tol. | l | | | D | Tol. | l |
| 1,65 mm | -0/+0.15 | 330 mm | | | 12,20 mm | -0/+0.30 | 330 mm |
| 1,80 mm | -0/+0.15 | 330 mm | | | 12,40 mm | -0/+0.30 | 330 mm |
| 2,20 mm | -0/+0.20 | 330 mm | | | 12,70 mm | -0/+0.30 | 330 mm |
| 2,70 mm | -0/+0.20 | 330 mm | | | 13,00 mm | -0/+0.30 | 330 mm |
| 3,25 mm | -0/+0.20 | 330 mm | | | 13,20 mm | -0/+0.30 | 330 mm |
| 3,40 mm | -0/+0.20 | 330 mm | | | 14,20 mm | -0/+0.30 | 330 mm |
| 3,70 mm | -0/+0.20 | 330 mm | | | 14,70 mm | -0/+0.30 | 330 mm |
| 4,20 mm | -0/+0.20 | 330 mm | | | 15,20 mm | -0/+0.30 | 330 mm |
| 4,40 mm | -0/+0.20 | 330 mm | | | 16,20 mm | -0/+0.45 | 330 mm |
| 4,70 mm | -0/+0.20 | 330 mm | | | 17,20 mm | -0/+0.45 | 330 mm |
| 5,20 mm | -0/+0.25 | 330 mm | | | 18,20 mm | -0/+0.45 | 330 mm |
| 5,70 mm | -0/+0.25 | 330 mm | | | 19,20 mm | -0/+0.45 | 330 mm |
| 6,20 mm | -0/+0.25 | 330 mm | | | 20,20 mm | -0/+0.45 | 330 mm |
| 6,40 mm | -0/+0.25 | 330 mm | | | 21,20 mm | -0/+0.55 | 330 mm |
| 6,55 mm | -0/+0.25 | 330 mm | | | 22,20 mm | -0/+0.55 | 330 mm |
| 6,70 mm | -0/+0.25 | 330 mm | | | 23,20 mm | -0/+0.55 | 330 mm |
| 7,20 mm | -0/+0.30 | 330 mm | | | 24,20 mm | -0/+0.55 | 330 mm |
| 7,70 mm | -0/+0.30 | 330 mm | | | 25,20 mm | -0/+0.65 | 330 mm |
| 8,20 mm | -0/+0.30 | 330 mm | | | 25,80 mm | -0/+0.65 | 330 mm |
| 8,40 mm | -0/+0.30 | 330 mm | | | 26,20 mm | -0/+0.65 | 330 mm |
| 8,70 mm | -0/+0.30 | 330 mm | | | 28,20 mm | -0/+0.65 | 330 mm |
| 9,20 mm | -0/+0.30 | 330 mm | | | 30,20 mm | -0/+0.65 | 330 mm |
| 9,70 mm | -0/+0.30 | 330 mm | | | 32,20 mm | -0/+0.65 | 330 mm |
| 10,20 mm | -0/+0.30 | 330 mm | | | 34,20 mm | -0/+0.65 | 330 mm |
| 10,20 mm | -0/+0.30 | 330 mm | | | 36,20 mm | -0/+0.65 | 330 mm |
| 10,40 mm | -0/+0.30 | 330 mm | | | 38,20 mm | -0/+0.70 | 330 mm |
| 10,70 mm | -0/+0.30 | 330 mm | | | 40,20 mm | -0/+0.70 | 330 mm |
| 11,20 mm | -0/+0.30 | 330 mm | | | 42,20 mm | -0/+0.70 | 330 mm |
| 11,70 mm | -0/+0.30 | 330 mm | | | 46,20 mm | -0/+0.70 | 330 mm |
